ABOUT US
The Fiberglass Suckerods™ experience is back in the oilfield, providing the finest sucker rod that has ever existed along with legendary customer service. SUPEROD® offers superior service and the longest lasting suckerods™. These rods come with a 2 year manufacturing warranty along with a money back guarantee.
The SUPEROD® is the most technologically advanced fiberglass suckerods™ in the world. This rod now has a patented end fitting with the best stress distribution of any end fitting that has ever been built. This gives you a product that will last longer and handle more load than any suckerods™ on the planet.
HISTORY
The company’s founder, Russ Rutledge is one of the original pioneers in fiberglass sucker rod technology. Mr. Rutledge spear headed the first long-term success of this technology in 1978 with the founding Fiberflex, Inc. Fiberflex experienced significant success and an unfriendly stockholder takeover was implemented in 1983, which resulted in Mr. Rutledge being bought out. He then founded Fiberglass Technologies, Inc. in 1985. This company began by refurbishing and selling existing fiberglass rods, which were refitted with a newly developed, patented end fitting. Fiberglass Technologies, Inc. acquired Fiberflex, Inc. in 2003 and formed the company known as FIBEROD. FIBEROD was a very successful manufacturer and seller of fiberglass sucker rods for eight years utilizing the innovative end fitting design developed by Mr. Rutledge at Fiberglass Technologies, Inc. FIBEROD was sold in May of 2008 to the Smith Group, an international company and was then acquired by Endurance Production Solutions, Inc. in 2016.
Because of the demand from former customers and the long-term relationships developed from over 30 years of innovation in the industry, Mr. Rutledge began developing and testing a new, cutting edge end-fitting design in late 2010. With the successful development of the new end-fitting design, Mr. Rutledge formed R2 R and D, LLC. in 2011, with the first rods being produced in the new Big Spring facility later that year. R2 R and D, LLC chose to brand the new rod, ”SUPEROD®” because its quality, strength, and durability far exceeded any other rod in the market. SUPEROD® is the most technologically advanced fiberglass sucker rod on the planet and is supported by the most experienced team in the industry. SUPEROD® is committed to building the finest product possible while offering the best service in the industry.
CORPORATE OFFICE
Billing | Applications | HR
610 S Main St
Big Spring, TX 79720
Office: 432.264.7500
Fax: 432.714.4723
SALES OFFICE
Find your Salesman now to learn more!
1508 E. FM 700
Big Spring, TX 79720
Office: 432.268.1000
Fax: 432.935.6741
PLANT OFFICE
If you need to place an order, call now!
Want a tour of our Plant?
3408 E 11th Place Ext
Big Spring, TX 79720
Office: 432.517.4145
Fax: 432.517.4528
SUCKERODS
SUPEROD® suckerods™ can be used in multiple artificial lift applications of oil and gas wells. Suckerods™ are connected together by either a standard or slim-hole coupling, to create a “rod string”. Suckerods™ strings can be thousands of feet long end to end, connecting the downhole pump to the production unit at the surface. We have three sizes and two temperature ranges for you to choose from – depending on the depth and volume of your well – to best fit your application.
SUCKERODS
DOWNLOAD
The only failure free suckerod™ in the industry with over 11,000 rod strings in the ground, and we still have a perfect record.
No other suckerod™ manufacturer even comes close, you can buy cheaper rods, but you can’t by a better rod.
For your best ROI buy the best and experience uninterrupted pumping for the life of your well and we guarantee it. We guarantee our rods to be failure free for 2 years, if they fail and its our fault we will not only replace the rods, but we will also pay your pulling costs.
90,000 / 115,000
TENSILE STRENGTH (PSI) MIN/MAX
40,000
MAX WORKING STRESS (PSI)
23,000 / 40,000
MAX WORKING LOAD (LBS) MIN/MAX
29,000 / 60,000
MAX SHORT TERM LOAD (LBS) MIN/MAX
Operating properties are limited by rod size, steel end fitting and couplings.
COUPLINGS & CROSS OVER COUPLINGS
Class T and Spray Metal couplings in standard full size and slim-hole size. Combination couplings and sub couplings are also available upon customer’s request. Thread rolling process to produce couplings. It creates a compressive stress at the root of the threads, overcome the traditional weak point of cut-thread couplings.
ROD GUIDES & GUIDED RODS
SUPEROD® Rod Guides are placed on the fiberglass Rod body to the customers specification. These Rod guides are produced and installed in our plant using a process unique to SUPEROD®.
Testing proves that SUPEROD® guides handle a greater side load than smaller molded on Rod guides used by the competitors. If you need to stabilize your Rod string then you need SUPEROD® Rod Guides.
We carry 1.25″ with 5 guides or 10 guides for 2 7/8″ tubing. We carry 1″ with 5 guides for 2 7/8″ tubing or 2 3/8″ tubing. We also have high temp guided rods.
ROD GUIDES & GUIDED RODS
SUPEROD® Rod Guides are designed specifically for use on SUPEROD® fiberglass rods and are installed using a proprietary attachment process. Our installation process insures the guides will stay in place and resist slippage on the rod. SUPEROD® guides have over twice the erodible area of conventional, molded-on guides.Built to your specifications in rapid fashion, our new patent pending SUPEROD® rod guide out performs all other rod guides and we will be happy to prove it in our facility. Our push off test have proven SUPEROD® Guides will withstand more than twice the push off pressure than any other commercially available guide and we guarantee it.
SINKER BARS & MUD ANCHORS
SINKERBARS
SUPEROD stocks All American Sinker Bars for you convenience. All American Sinker Bars is based out of Odessa, TX.
SINKER BARS
American Sinker Bars are manufactured from the finest quality, hot-rolled, cold-drawn carbon or alloy steel bar stock. The hot-rolled, cold drawn carbon or alloy steel bar stock, in concert with an advanced pin design, permits these sinker bars to improve the overall fatigue strength and service life in the toughest, most demanding, rod-pumped artificial lift applications.Hot rolled, cold drawn bar stock improve the mechanical properties, surface integrity, and dimensional accuracy, tolerance and shape of American Sinker Bars over sinker bars available from other manufacturers who don’t use the cold drawn method. it is possible to increase the yield strength of the steel bar stock while keeping the diameter, straightness and out-of round tolerance more consistent and without much increase in the tensile strength or hardness of the sinker bar. The overall result of the hot rolled, cold drawn material and advanced pin design is a sinker bar with increased fatigue endurance, strength, toughness and an improved surface finish on the O.D.; which removes irregularities that may otherwise result in abrasion and wear to your production tubing.
MUD ANCHORS
SUPEROD manufactures a Mud Anchor made completely of fiberglass.
MUD ANCHORS
Superod manufactures a 100% fiberglass mud anchor for your gas separation needs. It is resistant to corrosion. 32’ x 3.5” OD 3” ID
